Capacitive touch panel are made of an Insulator that is coated with a transparent Conductor,Typically, Capacitive touch panels consist of glass as the insulator coated in indium tin Oxide(ITO).The human body is also an electrical conductor, so when the human body comes into contact with the Capacitive Touch panel, the touch panel's electrostatic field becomes distorted.It is this distortion that is then read by the touch panel controller and,depend on the program written,the display will respond accordingly.

Features: Increased ruggedness
               Improved durability
               Condensation
               Extended temperature range
               Anti-reflective,Anti-finger print & scratch


Applications:  Bank system, Medical, Military,ATM ,Vending machine,etc.


Filter Results

RESET
ADD TO INQUIRY
Select Picture Model_No Brand Size Brightness Resolution Viewing_angle Lamp_Type Application Signal_interface Aspect_Ratio Original_HB With_Touch_Function With_Metal_Cover
JFC121CFSS.V0 JFCVision 12.1inch 175cd/m2 1024*768 45/45/20/45 (Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC156CMYY.V6 JFCVision 15.6 inch 340cd/m2 1920(RGB)*1080 ,FHD 85/85/85/85 (Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC156CFYS.V0 JFCVision 15.6inch 340cd/m2 3840*2160 85/85/85/85 (Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC280CFSS.V1 JFCVision 28 inch 700 cd/m2 1920*360 89/89/89/89 WLED KIOSK LDVS - - Touchscreen -
JFC280CMSS.V0 JFCVision 28 inch 1500 cd/m2 1920*360 89/89/89/89(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC280CFSS.V0 JFCVision 28 inch 1500 cd/m2 1920*360 89/89/89/89 WLED KIOSK LDVS - - Touchscreen -
JFC280CMSS.V1 JFCVision 28 inch 700 cd/m2 1920*360 89/89/89/89(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC170CFSS.V0 JFCVision 17 inch 250cd/m2 1280(RGB)*1024 85/85/80/80(Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC170CFYS.V0 JFCVision 17 inch 350 cd/m2 1280(RGB)*1024 85/85/80/80(Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC170CMYY.V0 JFCVision 17 inch 350 cd/m2 1280(RGB)*1024 85/85/80/80(Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC170CMSS.V0 JFCVision 17 inch 250 cd/m2 1280(RGB)*1024 85/85/80/80(Typ.)(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
JFC185CFYS.V0 JFCVision 18.5 inch 350 cd/m2 1920(RGB)*1080 ,FHD 89/89/89/89(L/R/U/D) WLED KIOSK LDVS - - Touchscreen -
